Shacman f3000 10 wheeler dump truck Safe, more powerful. It has strong conveying capacity and is equipped with leaf spring design, which fully meets the carrying capacity of mining transportation and is more suitable for complex working conditions.
Shacman 10 wheeler dump truck adopts key advanced technology and is a product for Chinese market and international market. It is a new generation of high-end, advanced and mature heavy trucks.
The Shacman 10 wheeler dump truck is powered by the well-known Weichai engine in the industry. The maximum output horsepower is 380 horsepower, which is fast and powerful. The design on the axle adopts a wheel-side reduction axle, which increases the bearing capacity of the Shacman dump truck.
Shacman F3000 10 Wheeler Dump Truck for Sale - Shacman
Shacman F3000 10 Wheeler Dump Truck for Sale - Shacman
Shacman F3000 10 Wheeler Dump Truck for Sale - Shacman
Brand: Shacman Dump Truck
Drive model: right driven hand, 6X4
Clutch: ∮430 diaphragm clutch
Gearbox Model: Fast Fuller 10JSD180 gearbox with 10 forward and 2 reverse
Propeller shaft: ∮180 contrite gear propeller shaft
Front axle: Man technology 9.5 tons
Rear axle: 16 tons with hub reduction
Rear suspension: inverted leaf spring with stabilizer
Instrument panel: Combined instrument panel
Tyre: 12.00R20/12.00R22.5,11ps
Cabin: Man F3000 flat head with two seats and one sleep with A/C, rear windows, mechanical clerestory, hydraulic suspension cab, hydraulic chair, metal bumper, USB, electrically reversal cab
Other: enlargement radiator, ABS
Shacman 10 Wheeler Dump Truck Engine:
Engine model: Weichai WP10.340E22
Power(Kw/Hp): 340
Speed(r/min):2200
Max torque(N.m):1400
Type: electrically control, diesel engine, 4-stroke,6-cylinder in line, inter-cooling and turbo-charging, euro-3 emission standard
Displacement(L):9.726
Shacman 10 Wheeler Dump Truck Steering
Model: 8098 integral circuiting ball power steering
Ratio:22.2-26.2:1
Brakes
Running brake: Dual circuiting compressed air brake
Parking brake: Rear wheel power spring brake
Auxiliary brake: Engine exhaust brake
Electrics
Starter: 5.58kw,24V
Alternator: 1.54kw(28V,55A)
Battery: 165AH
Dimension (mm)
Wheel base:3775+1400
Front-wheel track:1525
Rear wheel track:2036
Front overhang: 1850
Rear overhang: 850
Approach angle: 28°
Departure angle: 30°
Overall length: 8550
Overall width:2550
Overall height: 3450
Body dimension: 5200/5400/5800X2300X1300/1400/1500(bottom 8mm and side 6mm)
Fuel tank(L): 380L
Weight(Kg)
GVW:50000
Front axle loading capacity: 9500
Rear axle loading weight: 16000X2
Performance:
Max. running speed(km/h):80
Max. climbing capacity(%):30
Min. ground clearance(mm):318
Fuel consumption(L/100km):40
